20-Port 16X 3.0 SATA Expansion Card with Cables & Power Cable, 6Gbps SATA 3.0 PCIe Card (Black, 5 * 1064+1812 Chip)

Specification: Product name: PCI-E 20port 3.0 SATA Expansion Card Expansion interface: 20 ports SATA3.0 interfaces Chipset: 6*ASM1064+ASM1812*1 main control chip PCI Express Gen.3 bus interface Support Serial ATA Revision 3.0 and backward compatible Provide 20 standard rate Serial ATA 7-Pin connectors Support Serial-ATA(SATA) Gen III 6Gb/s hard disk, and backward compatible with SATA I/II Supports connection of SATA I/II/III hard drives and CD burnersDescriptions SATA Controller: Compliant with Serial ATA Specification 3.1. Communication speeds of 6.0Gbps, 3.0Gbps and 1.5Gbps are supported. Programmable transmitter signal levels are supported. Gen 1i, Gen 1x, Gen 2i, Gen 2m, Gen 2x and Gen 3i are supported. Supports AHCI 1.0 programming interface. Native Command Queuing (NCQ) is supported. Porter FIS-based handover or command-based handover is supported. Partial and sleep power management states are supported. Supports staggered rotationPCI Express: Compliant with PCI Express 2.0 specification, PCIe* 2.0 endpoint device Supports communication speeds of 2.5 Gbps and 5.0 Gbps AHCI programming interface registers supporting SATA controllers Product-enabled power management Support for error reporting, recovery and correction Support Message Signaled Interrupt (MSI)Operating Systems: 1.Works onWindows XP/Vista/Win 7/Win 8/Server 2003/Server 2008 R2./Linux 2.6.x and above 2. One available PCI Express slotThings to know before buying: The driver can be easily configured as 20 independent ports, the product is the system supports RAID function, if the computer does not support RAID, it cannot be supported.Package Contents: PCIE 20port 16X SATA controller card*1 SATA cable *20 15Pin SATA to 5SATA Power Cable*1 Instructions* 1

• With this PCI-E 20port 3.0 SATA 16X card, you can add 20 SATA 3.0 6 Gbps devices to your computer (No need to install a driver and contact the seller if need the driver).
• Use the 6*ASM1064+ASM1812*1 chip to improve card stability and compatibility.The PCIe SATA card contains 20 SATA cables to simplify the connection!
• Connect 20 mass storage devices at the same time. Work withWindows XP/Vista/Win 7/Win 8/Server 2003/Server 2008 R2./Linux 2.6.x and above
• PCI-E SATA Expansion CaSupport Serial-ATA (SATA) Gen III 6Gb/s hard disk, and backward compatible with SATA I/II, support connection to SATA I/II/III hard disk drive and CD writer.rd,Connecting 20 mass storage devices at the same time.
